This Access control/reader is designed for supporting 125KHZ HID and EM card &PIN. It is anti-vandal and waterproof design. 3 access modes optional. It an ideal choice for door access not only for small shops and domestic households but also for commercial and industrial applications such as factories, warehouse, laboratories, banks and prisons.

· Metal structure, anti-vandal, safe, waterproof design.

· Pulse mode, toggle mode

· 2,100 users + 10 group duress PIN/Card (Zone 1:2,000 + Zone 2:100).

· Support 3 Modes Access: Card, PIN, Card+PIN.

· Card Type: 125KHz EM & HID card, PIN length: 4-8 digits.

· Very Low Power Consumption ( ≤35mA), long service life and stable performance.

· Application in High-Security Places: warehouses, banks, prisons, etc

· High speed search: filled with 2,000 users, the search time< 0.1 seconds

· Backlight keypad.

· With manager cards for adding or deleting card user easily.

· Wiegand 26-37 bit input & output, can be programmed.

· Support door bell connection(Zone 2)

· Protective Properties: IP65 fully-potted.

· With anti-disassemble, alarm function, anti-static interference 15KV.

Specifications

· Operating Voltage: 12-18V AC / 12-24V DC

· Card Type: 125KHz EM & HID

· Adjustable Door Relay Time: 1-99s

· Static Current: ≤35mA

· Wiegand Interface: Wiegand 26-37 bit

· Card Read Rang: 3-6cm

· Reader Induction Time: ≤0.1s

· Operating Temperature: -40℃～60℃

· Operating Humidity: 0-95%

· Lock Output Load: 1A

· Alarm Output Load: 3A

· Antistatic: 15KV

· Environment: Conforms to IP65

· Wiring Length: 90-100cm

· Dimensions:  128mm×82mm×28m.
